Specs Highlights:
Reticle
5 types, 4 colors, on/off
Eye relief
≥ 60 mm
Weight
970 g ( 2.14 lb)
Magnification
4x
| Palettes | Black Hot, White Hot, Red Hot, Fusion |
| Reticle | 5 types, 4 colors, on/off |
| Boresight Adjustment | Digital Controlled |
| Boresight Increment | 0.09 mil / 0.31 MOA |
| Distance Measurement | Yes (Stadiametric) |
| Scene Mode | Jungle, Recognition |
| Picture In Picture Mode (PIP) | Yes |
| Video Recording | Yes |
| Defective Pixels Correction (DPC) | Yes |
| Uniformity Correction | Auto, Manual, External Correction |
| Digital Magnification | 4x - 32x |
| Detector type | 12μm, Uncooled, 50 Hz, < 35 mK (25°C, F# = 1.0) |
| Standby Mode | Yes |
| Resolution | 384 × 288 |
| Snapshot | Yes |
| Lens system | 50 mm; F/1.0 |
| Field of view (H × X) | 5.4° × 4.0° |
| Digital zoom | 1×, 2×, 4×, 8× |
| Diopter adjustment range | -5 to +5 dpt |
| Eye relief | ≥ 60 mm |
| Display | Two 18650 Rechargeable Batteries (built-in) and one CR123 Battery |
| Battery Type | 1024×768, 50 Hz, OLED |
| Wi-Fi | Yes |
| CVBS Output | Yes (via USB) |
| Battery Life (Operating) | Up to 15 hr |
| Power supply | 5 VDC/2 A, USB Type-C Supports QC3.0 |
| Degree of Protection | IP67 |
| Weight | 970 g ( 2.14 lb) |
| Overall Dimensions | 420 × 78 × 82 mm (16.5 × 3.1 × 3.2 in) |
| Magnification | 4x |
