Specs Highlights:
Reticle
5 types, 4 colors, on/off
Eye relief
45 mm
Weight
535 g (1.18 lb)
| Palettes | Black Hot, White Hot, Red Hot Fusion |
| Reticle | 5 types, 4 colors, on/off |
| Drop Test Height | 1.5m (4.9 feet) |
| Boresight Adjustment | Digital Controlled |
| Distance Measurement | Yes (Stadiametric Rangefinder) |
| Scene Mode | Jungle, Recognition |
| Picture In Picture Mode (PIP) | Yes (2× Zoom) |
| Video Recording | Yes |
| Defective Pixels Correction (DPC) | Yes |
| Uniformity Correction | Auto, Manual, External Correction |
| Detector type | 12μm, Uncooled, 50 Hz |
| Standby Mode | Yes |
| Resolution | 640 × 512 |
| Detection Range | 1,750m/yd |
| Lens system | 35 mm; F/1.0 |
| Optical magnification | 2x |
| Field of view (H × X) | 12.5° × 10.0° |
| Digital zoom | 1×, 2×, 4×, 8× |
| Eye relief | 45 mm |
| Display | 0.39-inch, OLED, 1024×768 50 Hz |
| Storage | Built-in EMMC (16 GB) |
| Battery Type | Two CR123 (3V) Lithium or two RCR123 (up to 4.2V) Rechargeable Batteries |
| CVBS Output | Yes (via USB) |
| Battery Life (Operating) | Up to 4.5 hr |
| External power supply | 5 VDC/2 A, USB Type-C interface |
| Operating Temperature Range | -20°C to +55°C (-4°F to +131°F) |
| Degree of Protection | IP67 |
| Weight | 535 g (1.18 lb) |
| Overall Dimensions | 187× 63 × 80 mm (7.4 × 2.5 × 3.1 in) |
| Package Includes | Thermal Imaging Rifle Scope, Mount, USB Cable, Lens Cloth, Manual |
