Palettes
|
Black Hot, White Hot, Red Hot Fusion
|
Reticle
|
5 types, 4 colors, on/off
|
Drop Test Height
|
1.5 m (4.9 ft)
|
Boresight Adjustment
|
Digital Controlled
|
Boresight Increment
|
0.15 mil / 0.51 MOA
|
Scene Mode
|
Yes
|
Picture In Picture Mode (PIP)
|
Yes
|
Hotspot
|
Yes
|
Detector type
|
12 μm VOx Uncooled Focal Plane Arrays
|
Response Waveband
|
8 μm to 14 μm
|
FFC (Flat Field Correction)
|
Auto, Manual, External Correction
|
Highest Temperature Spot Tracking
|
Yes
|
Standby Mode
|
Yes
|
Refresh rate
|
Sensor 50Hz / OLED 50Hz
|
Aperture
|
F1.0
|
Resolution
|
640 × 512
|
Laser Rangefinder
|
Up to 600 m, ±2 m accuracy
|
Laser Wavelength
|
905 nm
|
Detection Range
|
2,500m/yd
|
Optical magnification
|
2.5x – 20x
|
Lens (focal length)
|
50 mm
|
Field of view (H × X)
|
8.78° × 7.03°
|
Digital zoom
|
1x, 2x, 4x, 8x
|
Monitor
|
1024x768, 0.39 inch, OLED
|
Eye relief
|
45 mm
|
Storage
|
Built-in 16 GB EMMC
|
Record Video
|
On-board video recording
|
Capture Snapshot
|
Yes
|
Battery Type
|
One 18650 (3.7V) Lithium Rechargeable Batteries
|
CVBS Output
|
Yes (via USB)
|
Battery Operating Time
|
Up to 4.5 hours
|
Battery Capacity Display
|
Yes
|
External power supply
|
5 VDC/2 A, USB Type-C
|
Operating Temperature Range
|
-20°C to 55°C (-4°F to 131°F)
|
Weight
|
722 g (1.59 lb)
|
Overall Dimensions
|
210 x 74 x 109 mm (8.3 × 2.9 × 4.3 in)
|
Protection Level
|
IP67
|
