Specs Highlights:
Magnification
3 - 12x
Objective Lens
40mm
Reticle
AMX IR
Parallax
Side Focus
Focal Plane
SFP (Second Focal Plane)
Field of View
43.7 - 10.9ft @100yds, 14.6 - 3.6m @100m
Field of View (°)
8.3 - 2.1
Eye Relief
3in, 76mm
Exit Pupil
0.52 - 0.13″, 13.3 - 3.3mm
Length
10.9in, 277mm
Weight
20.8oz, 589g
| Scope Tube | 30mm |
| Magnification | 3 - 12x |
| Objective Lens | 40mm |
| Reticle | AMX IR |
| Illumination | 6 Levels (Red) |
| Illumination Control | Stepped Rheostat with Off Positions In-between |
| Parallax | Side Focus |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 16 Layers |
| Optical System | System H2 |
| Field of View | 43.7 - 10.9ft @100yds, 14.6 - 3.6m @100m |
| Field of View (°) | 8.3 - 2.1 |
| Eye Relief | 3in, 76mm |
| PX/Focus (Error free from) | 10yds - ∞, 9m - ∞ |
| Click Value | 1⁄ 10MRAD |
| Exit Pupil | 0.52 - 0.13″, 13.3 - 3.3mm |
| Turret Type (Elevation) | Target, Capped, Resettable |
| Elevation Turret Clicks (max) | 30 MRAD |
| Turret Type (Windage) | Target, Capped, Resettable |
| Windage Turret Clicks (max) | 30 MRAD |
| Ocular Type | Fast Focus |
| Power Selector | Knurled Posi-Grip |
| Length | 10.9in, 277mm |
| Weight | 20.8oz, 589g |
