Specs Highlights:
Magnification
10x
Objective Lens
44mm
Reticle
AMX IR
Parallax
Side Focus
Focal Plane
SFP (Second Focal Plane)
Field of View
12ft @100yds, 4m @100m
Field of View (°)
2.3
Eye Relief
4in, 102mm
Exit Pupil
0.17″, 4.4mm
Length
13in, 330mm
Weight
22.6oz, 640g
| Scope Tube | 30mm |
| Magnification | 10x |
| Objective Lens | 44mm |
| Reticle | AMX IR |
| Illumination | 6 Levels (Red) |
| Illumination Control | Stepped Rheostat with Off Positions In-between |
| Parallax | Side Focus |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 16 Layers |
| Optical System | System H2 |
| Field of View | 12ft @100yds, 4m @100m |
| Field of View (°) | 2.3 |
| Eye Relief | 4in, 102mm |
| PX/Focus (Error free from) | 10yds - ∞, 9m - ∞ |
| Click Value | 1⁄ 10MRAD |
| Exit Pupil | 0.17″, 4.4mm |
| Turret Type (Elevation) | Target, Capped, Resettable |
| Elevation Turret Clicks (max) | 16 MRAD |
| Turret Type (Windage) | Target, Capped, Resettable |
| Windage Turret Clicks (max) | 16 MRAD |
| Ocular Type | Fast Focus |
| Power Selector | Rubber Coated Posi-Grip |
| Length | 13in, 330mm |
| Weight | 22.6oz, 640g |
