Specs Highlights:
Magnification
4 - 16x
Objective Lens
50mm
Reticle
LR Dot (8x)
Parallax
Side Focus
Focal Plane
SFP (Second Focal Plane)
Field of View
31.2 - 7.8ft @100yds, 10.4 - 2.6m @100m
Field of View (°)
6 - 1.5
Eye Relief
4in, 102mm
Exit Pupil
0.49 - 0.12″, 12.5 - 3.1mm
Length
14.5in, 369mm
Weight
22.7oz, 644g
| Scope Tube | 30mm |
| Magnification | 4 - 16x |
| Objective Lens | 50mm |
| Reticle | LR Dot (8x) |
| Illumination | 6 Levels (Red) |
| Illumination Control | Stepped Rheostat with Off Positions In-between |
| Parallax | Side Focus |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 18 Layers |
| Optical System | System H5 |
| Field of View | 31.2 - 7.8ft @100yds, 10.4 - 2.6m @100m |
| Field of View (°) | 6 - 1.5 |
| Eye Relief | 4in, 102mm |
| PX/Focus | 15yds - ∞, 14m - ∞ |
| Click Value | 1⁄ 4MOA |
| Exit Pupil | 0.49 - 0.12″, 12.5 - 3.1mm |
| Turret Type (Elevation) | Exposed, Locking, Resettable |
| Elevation Turret Clicks (max) | 75 MOA |
| Turret Type (Windage) | Exposed, Locking, Resettable |
| Windage Turret Clicks (max) | 75 MOA |
| Ocular Type | Fast Focus |
| Power Selector | Rubber Coated Posi-Grip |
| Length | 14.5in, 369mm |
| Weight | 22.7oz, 644g |
