Specs Highlights:
Magnification
2.5 - 10x
Objective Lens
50mm
Reticle
LR Dot (8x)
Parallax
Fixed
Focal Plane
SFP (Second Focal Plane)
Field of View
49.8 - 12.5ft @100yds, 16.6 - 4.2m @100m
Field of View (°)
9.5 - 2.4
Eye Relief
4in, 102mm
Exit Pupil
0.79 - 0.2″, 20 - 5mm
Length
13.1in, 334mm
Weight
21.6oz, 612g
| Scope Tube | 30mm |
| Magnification | 2.5 - 10x |
| Objective Lens | 50mm |
| Reticle | LR Dot (8x) |
| Illumination | 6 Levels (Red) |
| Illumination Control | Stepped Rheostat with Off Positions In-between |
| Parallax | Fixed |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 18 Layers |
| Optical System | System H5 |
| Field of View | 49.8 - 12.5ft @100yds, 16.6 - 4.2m @100m |
| Field of View (°) | 9.5 - 2.4 |
| Eye Relief | 4in, 102mm |
| PX/Focus | 100yds, 91m |
| Click Value | 1⁄ 4MOA |
| Exit Pupil | 0.79 - 0.2″, 20 - 5mm |
| Turret Type (Elevation) | Capped, Low-Profile, Resettable |
| Elevation Turret Clicks (max) | 140 MOA |
| Turret Type (Windage) | Capped, Low-Profile, Resettable |
| Windage Turret Clicks (max) | 140 MOA |
| Ocular Type | Fast Focus |
| Power Selector | Rubber Coated Posi-Grip |
| Length | 13.1in, 334mm |
| Weight | 21.6oz, 612g |
