Specs Highlights:
Magnification
6 - 24x
Objective Lens
50mm
Reticle
FFP Half Mil Dot (24x)
Parallax
Side Focus
Focal Plane
FFP (First Focal Plane)
Field of View
21.0 - 5.2ft @100yds, 7 - 1.7m @100m
Field of View (°)
4 - 1
Eye Relief
3.5in, 90mm
Exit Pupil
0.33 - 0.08″, 8.3 - 2.1mm
Length
14.9in, 378mm
Weight
26.6oz, 755g
| Scope Tube | 30mm |
| Magnification | 6 - 24x |
| Objective Lens | 50mm |
| Reticle | FFP Half Mil Dot (24x) |
| Illumination | 5 Levels (Red & Green) |
| Illumination Control | Stepped Rheostat |
| Parallax | Side Focus |
| Focal Plane | FFP (First Focal Plane) |
| Lens Coating | Fully Multi-Coated - 11 Layers |
| Optical System | System H2 |
| Field of View | 21.0 - 5.2ft @100yds, 7 - 1.7m @100m |
| Field of View (°) | 4 - 1 |
| Eye Relief | 3.5in, 90mm |
| PX/Focus (Error free from) | 10yds - ∞, 9m - ∞ |
| Click Value | 1⁄ 10MRAD |
| Exit Pupil | 0.33 - 0.08″, 8.3 - 2.1mm |
| Turret Type (Elevation) | Exposed, Locking, Resettable |
| Elevation Turret Clicks (max) | 17 MRAD |
| Turret Type (Windage) | Exposed, Locking, Resettable |
| Windage Turret Clicks (max) | 17 MRAD |
| Ocular Type | Fast Focus |
| Power Selector | Knurled Posi-Grip |
| Length | 14.9in, 378mm |
| Weight | 26.6oz, 755g |
