Specs Highlights:
Magnification
2 - 7x
Objective Lens
32mm
Reticle
Mil Dot IR
Parallax
Adjustable Objective
Focal Plane
SFP (Second Focal Plane)
Field of View
46.6 - 14.1ft @100yds, 15.5 - 4.7m @100m
Field of View (°)
8.9 - 2.7
Eye Relief
3.5in, 90mm
Exit Pupil
0.63 - 0.18″, 16 - 4.6mm
Length
11.5in, 292mm
Weight
15.9oz, 450g
| Scope Tube | 1 Inch |
| Magnification | 2 - 7x |
| Objective Lens | 32mm |
| Reticle | Mil Dot IR |
| Illumination | 5 Levels (Red & Green) |
| Illumination Control | Stepped Rheostat |
| Parallax | Adjustable Objective |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 11 Layers |
| Optical System | System H2 |
| Field of View | 46.6 - 14.1ft @100yds, 15.5 - 4.7m @100m |
| Field of View (°) | 8.9 - 2.7 |
| Eye Relief | 3.5in, 90mm |
| PX/Focus | 5yds - ∞, 5m - ∞ |
| Click Value | 1⁄ 4MOA |
| Exit Pupil | 0.63 - 0.18″, 16 - 4.6mm |
| Turret Type (Elevation) | Capped, Low-Profile, Resettable |
| Elevation Turret Clicks (max) | 140 MOA |
| Turret Type (Windage) | Capped, Low-Profile, Resettable |
| Windage Turret Clicks (max) | 140 MOA |
| Ocular Type | Fast Focus |
| Power Selector | Knurled Posi-Grip |
| Length | 11.5in, 292mm |
| Weight | 15.9oz, 450g |
