Specs Highlights:
Magnification
4 - 12x
Objective Lens
50mm
Reticle
Mil Dot IR
Parallax
Fixed
Focal Plane
SFP (Second Focal Plane)
Field of View
26.2 - 8.7ft @100yds, 8.7 - 2.9m @100m
Field of View (°)
5 - 1.7
Eye Relief
3.5in, 90mm
Exit Pupil
0.49 - 0.17″, 12.5 - 4.2mm
Length
13.4in, 341mm
Weight
17.5oz, 497g
| Scope Tube | 1 Inch |
| Magnification | 4 - 12x |
| Objective Lens | 50mm |
| Reticle | Mil Dot IR |
| Illumination | 5 Levels (Red & Green) |
| Illumination Control | Stepped Rheostat |
| Parallax | Fixed |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 11 Layers |
| Optical System | System H2 |
| Field of View | 26.2 - 8.7ft @100yds, 8.7 - 2.9m @100m |
| Field of View (°) | 5 - 1.7 |
| Eye Relief | 3.5in, 90mm |
| PX/Focus | 100yds, 91m |
| Click Value | 1⁄ 4MOA |
| Exit Pupil | 0.49 - 0.17″, 12.5 - 4.2mm |
| Turret Type (Elevation) | Capped, Low-Profile, Resettable |
| Elevation Turret Clicks (max) | 80 MOA |
| Turret Type (Windage) | Capped, Low-Profile, Resettable |
| Windage Turret Clicks (max) | 80 MOA |
| Ocular Type | Fast Focus |
| Power Selector | Knurled Posi-Grip |
| Length | 13.4in, 341mm |
| Weight | 17.5oz, 497g |
