Specs Highlights:
Magnification
3 - 9x
Magnification
40mm
Reticle
30/30 Duplex
Parallax
Fixed
Focal Plane
SFP (Second Focal Plane)
Field of View
39 - 12.7ft @100yds, 13 - 4.2m @100m
Field of View (°)
7.4 - 2.4
Eye Relief
3.5in, 90mm
Exit Pupil
0.52 - 0.17″, 13.3 - 4.4mm
Length
12.4in, 315mm
Weight
14.2oz, 402g
| Scope Tube | 1 Inch |
| Magnification | 3 - 9x |
| Magnification | 40mm |
| Reticle | 30/30 Duplex |
| Parallax | Fixed |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 11 Layers |
| Optical System | System H2 |
| Field of View | 39 - 12.7ft @100yds, 13 - 4.2m @100m |
| Field of View (°) | 7.4 - 2.4 |
| Eye Relief | 3.5in, 90mm |
| PX/Focus | 100yds, 91m |
| Click Value | 1⁄ 4MOA |
| Exit Pupil | 0.52 - 0.17″, 13.3 - 4.4mm |
| Turret Type (Elevation) | Capped, Low-Profile, Resettable |
| Elevation Turret Clicks (max) | 100 MOA |
| Turret Type (Windage) | Capped, Low-Profile, Resettable |
| Windage Turret Clicks (max) | 100 MOA |
| Ocular Type | Fast Focus |
| Power Selector | Knurled Posi-Grip |
| Length | 12.4in, 315mm |
| Weight | 14.2oz, 402g |
