Description
The VX-5HD Gen 2 1-5x24mm, with adjustments in metric units, is built for speed, awareness and precision in dense cover or wide-open terrain. Its wide field of view gives hunters the edge in fast-changing environments—whether you're tracking moving game in the timber or scanning wide-open terrain. It delivers incredible optical clarity and class-leading glare reduction in a lightweight, ultra-rugged build that won’t let you down.
Designed around our Professional-Grade Optical System, the VX-5HD Gen 2 1-5x24mm combines premium light transmission with outstanding glare control to deliver sharp, high-contrast images—especially in backlit conditions and challenging terrain. The versatile 5:1 zoom ratio excels at both close-range precision and mid-range engagements.
A Guard-Ion coating keeps lenses clear by repelling water, dirt, and smudges, while our illuminated reticle, competition-grade adjustments,fast-focus eyepiece, and integrated throw lever help you acquire targets faster and with more confidence. Please note that this particular model, the 1-5 x 24, has a capped, pop-up elevation dial and does NOT come with our Custom Dial System® featuring our tool-free SpeedSet™ elevation dial.
Waterproof, fogproof, and built to take abuse, the VX-5HD Gen 2 is engineered, machined, and assembled in the USA and backed by our Lifetime Guarantee. No paperwork. No receipt. No charge.
Features
- 5:1 Zoom Ratio
- Professional-Grade Optical System
- Guard-Ion Lens Coating
- High-Definition Performance
- Integrated Throw Lever
- Illuminated Reticle
- Motion Sensor Technology (MST)
- Waterproof, Fogproof, & Shockproof
- Leupold Lifetime Guarantee
Specs
| Battery Type | CR2032 |
| Daylight Bright Illumination | Yes |
| Elevation Adjustment Type | Pop-Up Rezero |
| Magnification Type | Variable |
| Reticle Focal Plane | Second Focal Plane |
| Reticle | Illum. FireDot 4 Fine |
| Rezero Type | Pop-Up |
| Reticle Type | Illuminated |
| Switch Type | Push Button |
| Windage Adjustment Type | Pop-Up Rezero |
| Weight (oz) | 15 |
| Elevation Adjustment Value per Click | 1cm @ 100m |
| Elevation Adjustment Range (MOA) | 180 |
| Elevation Adjustment Range (MIL) | 52.4 |
| Elevation Adjustment Range (cm @ 100m) | 524 |
| Elevation Adjustment Per Revolution | 80CM @ 100M |
| Elevation Dial Travel Limit | Total Scope Travel |
| Windage Adjustment Value per Click | 1cm @ 100m |
| Windage Adjustment Range (MOA) | 180 |
| Windage Adjustment Range (MIL) | 52.4 |
| Windage Adjustment Range (cm @ 100m) | 524 |
| Windage Adjustment Per Revolution | 80CM @ 100M |
| Magnification Max | 5 |
| Magnification Min | 1 |
| Objective Lens Diameter (mm) | 52 |
| Linear FOV Low Mag (ft@100yds) | 115.5 |
| Linear FOV High Mag (ft@100yds) | 23.9 |
| Angular FOV Low Mag (Degrees) | 21.8 |
| Angular FOV High Mag (Degrees) | 4.6 |
| Eye Relief Low Mag (in) | 3.8 |
| Eye Relief High Mag (in) | 3.9 |
| Fixed Parallax-Free Distance (yd) | 150 |
| Minimum Parallax-Free Distance (yd) | 50 |
| Battery Life (hr), Low Intensity | 1600 |
| Battery Life (hr), Medium Intensity | 1000 |
| Battery Life (hr), High Intensity | 300 |
| Number of Illum Settings | 8 |
