Description
Accurate mil spacing on 20x magnification. With half mil spaced markings out beyond 5 mil in all directions, the 20x Half Mil is a versatile reticle that provides aim points no matter how extreme the conditions.
A series of crosses etched on the lower section of the reticle make for extra windage aimpoints and act to give an easy quick-glance method of counting which mil spacing you're aiming with. Outer posts are segmented into half mil spacing and 0.2 mil spacings, so can be used for bracketing and rangefinding.
Features
- Resettable locking turrets with witness window
- 30mm Mono-tube chassis
- Side Focus
- Illumination
- Side wheel - index-matched (removable)
- Ultra-wide Angle 24° FOV
- High volume eyebox
- 100mm eye relief
- Multi-LED high intensity reticle
- High grade, low dispersion Crown glass
- 18 layer Fully Multi-Coated lenses
- Zoom magnification throw lever (removable)
- Fast focus eyebell with lock ring
Specs
Specs Highlights:
Magnification
6.5 - 20x
Objective Lens
44mm
Reticle
20x Half Mil
Parallax
Side Focus
Focal Plane
SFP (Second Focal Plane)
Field of View
19.5 - 6.3ft @100yds, 6.5 - 2.1m @100m
Field of View (°)
3.7 - 1.2
Eye Relief
4in, 102mm
Exit Pupil
0.27 - 0.09″, 6.8 - 2.2mm
Length
13.3in, 339mm
Weight
24oz, 680g
| Scope Tube | 30mm |
| Magnification | 6.5 - 20x |
| Objective Lens | 44mm |
| Reticle | 20x Half Mil |
| Illumination | 6 Levels (Red) |
| Illumination Control | Stepped Rheostat with Off Positions In-between |
| Parallax | Side Focus |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 18 Layers |
| Optical System | System H5 |
| Field of View | 19.5 - 6.3ft @100yds, 6.5 - 2.1m @100m |
| Field of View (°) | 3.7 - 1.2 |
| Eye Relief | 4in, 102mm |
| PX/Focus (Error free from) | 10yds - ∞, 9m - ∞ |
| Click Value | 1⁄ 10MRAD |
| Exit Pupil | 0.27 - 0.09″, 6.8 - 2.2mm |
| Turret Type (Elevation) | Witness Window, Exposed, Locking, Resettable |
| Elevation Turret Clicks (max) | 28 MRAD |
| Turret Type (Windage) | Witness Window, Exposed, Locking, Resettable |
| Windage Turret Clicks (max) | 28 MRAD |
| Ocular Type | Locking Fast Focus |
| Power Selector | Knurled Posi-Grip with Removable Zoom Lever |
| Length | 13.3in, 339mm |
| Weight | 24oz, 680g |
