Description
The OSCAR8™ is a premium, angled eyepiece 27–55x80 mm spotting scope. Featuring SIG SAUER’s industry-leading HDX™ optical design combining extra-low dispersion glass with high light transmittance glass, SCHMIDT-PECHAN prism and fully multi-coated lenses to provide unmatched resolution, image contrast, color clarity, and image brightness. The spotting scope features a fast focus adjustment along with an ergonomically designed, durable, non-slip rubber armor to protect the OSCAR8 in any environment.
Features
- HDX Advanced optical system comprising both High Definition (ED) and High Transmittance (HT) glass for ultra-high resolution, optical performance, and light transmission
- SCHMIDT-PECHAN prism, combined with HD glass, provide unmatched chromatic and spherical aberration correction for clear, vibrant images
- Spectracoat™highly efficient, ultra-wide broadband, anti-reflection lens coatings reduce surface reflections to extremely low levels across the entire visible spectrum providing superior light transmission
- Angled eyepiece, combined with rotating tripod collar, provides the user with multiple viewing angles, to accommodate setup and usage in any terrain
- Comes equipped with a variable power eyepiece. This eyepiece can be locked into place or removed.
- Waterproof and fog proof, the OSCAR8 will provide unmatched performance in all environmental conditions
- Adjustable eyecups allow the user to optimize eye relief for use with or without glasses
- Lightweight and robust aircraft grade aluminum housing, combined with rubberized non-slip grip armor, ensures a lifetime of use in the worst conditions
- Custom SIG SAUER fitted neoprene cover included
- Covered by SIG SAUER’s INFINITE Guarantee™ and Electronics Limited Warranty, see website for full details.
- Assembled in USA
Specifications
| Objective Lens Diameter | 28 mm |
| Eye Relief | 18 mm |
| Field of View | 332 feet/1000 yards |
| ProductHeight | 4.6 inches |
| Exit Pupil | 3.5 mm |
| Angular Field of View | 6.2 degrees |
| Magnification | 8x |
| Interpupillary Distance | 55-72 mm |
| ProductWidth | 4.5 inches |
| ProductWeight | 14 oz |
| Close Focus | 6 feet |
Specs Highlights:
Magnification
27-55x
Weight
67.2 (oz)
Eye Relief
16-17
Field of View
1.4 - 2.0
Waterproof
Yes
| SKU | SOO82001 |
| Model | OSCAR8 |
| Color | Flat Dark Earth (FDE) |
| Magnification | 27-55x |
| Objective Lens Diameter | 80 mm |
| Overall Length | 15.27 (in) |
| Weight | 67.2 (oz) |
| Battery | N/A |
| Prism Type | Schmidt-Pechan |
| Carry Case Included | No |
| Carry Case | N/A |
| Frame Material | Magnesium |
| Grip Material | Rubber Armor |
| BDX Enabled | No |
| HDX Glass | Yes |
| Image Stabilization | No |
| Eye Relief | 16-17 |
| Focal Plane | Second |
| Field of View | 1.4 - 2.0 |
| Near Focus (M) | 5m |
| Coating Type | SpectraCoat, Lens Armor, HDX |
| Tripod Mount | Yes |
| Waterproof | Yes |
| Waterproof Rating | IPX7 |
| Warranty | SIG SAUER Electro-Optic Infinite Guarantee |
| Application | Long Range Distance |
