Specs Highlights:
Magnification
6 – 36 ×
Effective lens diameter
56 mm
Eye relief
80 – 90 mm (3.0 – 3.5 ")
Length
384 mm (15.1 ")
Magnification | 6 – 36 × |
Effective lens diameter | 56 mm |
Light transmission | 90% |
Exit pupil diameter | 8.8 – 1.6 mm |
Twilight factor | 17.7 – 44.9 |
Field of view at 100 m (yds) | 6.8 – 1.1 m (20.4 – 3.3 ft) |
Objective viewing angle | 3.9° – 0.6° |
Diopter adjustment range | + 3.0 |
Eye relief | 80 – 90 mm (3.0 – 3.5 ") |
Parallax setting | 10 m – ∞ (10.9 yds – ∞) |
Vertical adjustment range at 100 m | 32.0 MRAD |
Lateral adjustment range at 100 m | 14.6 MRAD |
Adjustment per click at 100 m | 0.1 MRAD |
Centre tube diameter | 34 mm |
Eyepiece tube diameter | 45 mm |
Objective tube diameter | 60 mm |
LotuTec | + |
Water resistance | 400 mbar |
Operating temperature | − 25°C |
Length | 384 mm (15.1 ") |
Weight (without inner rail) | 1107 g (39.1 oz) |
